PRO 750W

The PRO 750 is a sealed series of high frequency battery charger with wide-range AC input adapting to any single-phase grid worldwide with a peak efficiency of 94%, complying with CEC. The charger can be programmed for charging various types of battery packs.It is widely used for floor machines, golf carts, utility vehicles, pallet trucks, aerial work platforms,tow tractors, etc.

Highlighted Features:

User friendly LED indicators for AC source, battery status, charging, error.
Cooling convection cooling Auto-recharge for low voltage in maintenance mode.
OEM customizable & field replaceable AC / DC cabling.
Lithium Additional portable handle available.

Dimensions & Parameters

Safety & EMC

Battery Type Supported

Customization Flexibility

Clients & Case Study

Application Of The Product

Product Data Download

Related Recommended Products

Dimensions & Parameters

DC Output	24VDC	36VDC	48VDC
Max. DC output voltage	36V	54V	72V
Max. DC output cuttent	25A	18A	12A
Max. DC output power	750W
Max. C3 interlock current	7A
Battery type	Lead acid (wet / AGM / gel), lithium
Reverse polarity	Electronic protection with auto-reset
Short circuit	Electronic current limit

AC Input
AC input voltage range	85-270 VAC
Nominal AC input voltage	100-240VAC
Nominal AC input frequency	50 / 60Hz
Maximum AC input current	14.5A
Nominal AC input current	8.5A @ 100VAC	7A @ 120VAC
	3.7A @ 230VAC	3.5A @ 240VAC
Power factor	>0.99 @ 120VAC	>0.98 @ 230VAC

Regulatory
Effciency	90% at full load, 120 VAC, 48 VDC \| 92% at full load, 240 VAC, 48 VDC California Energy Commission (CEC) compliant
Safety (LVD)	UL1564, CSA 107.2, EN 60335-2-29
Emissions (EMC)	FCC Part 15 / ICES 003 Class A, EN55011, EN 61000-6-4
Immunity (EMC)	EN 61000-3-2, EN 61000-3-3, EN 61000-6-2

Mechanical
Dimensions	L196 x W170 x H155.3 mm
Weight	4.1 kg
AC input connector	IEC320 / C14 (requires country-specifc cord)
DC output connector	M6 threaded fasteners for ring terminals (field replaceable)
Service port	Sealed (IP66) USB 2.0 Host Port (Type A) with dust cover
Mounting holes	6.4mm (1/4”) diameter slots
Cooling	convection cooling
